UL-2085 Fireguard Tanks | Double Wall Tanks

Home » Double Wall Tanks » UL-2085 Fireguard Tanks

Steel Tank and Fabricating Corp. (STAFCO) manufactures UL-2085 listed Fireguard® tanks for customers who require robust fire protection, environmental safety, and built-in secondary containment. These tanks are engineered for high-risk fueling applications and stringent regulatory environments.

What Is a Fireguard® Tank?

A Fireguard® tank is a type of double wall aboveground storage tank (AST) that includes:

Inner steel primary tank
Outer steel secondary tank
Insulating concrete-like layer between the two walls
Built-in fire-resistance and impact protection

The layer of concrete-like substance between the walls allows the tank to withstand extreme heat and meet fire safety requirements beyond standard double wall designs.

Check out our helpful UL-2085 Fireguard® Tank FAQ

Key Benefits

UL-2085 Listed for fire-resistant construction
Two-hour fire rating (per UL-2085 testing standards)
Protected against projectile and vehicle impact
Built-in secondary containment
Optional ballistics and explosion resistance, depending on configuration

Common Applications

Fireguard® tanks are widely used in locations where additional safety measures are mandated, such as:

Fueling stations in urban areas
Emergency generator fuel storage
Military and government installations
Hospitals and healthcare campuses
Data centers and critical infrastructure sites

Design and Customization

Available in a range of sizes and capacities, Fireguard® tanks can be built with:

Carbon steel construction
Horizontal or vertical orientation
Pump platforms, monitoring equipment, ladders, and safety fittings
Custom nozzles and configurations to meet your facility layout

Built for Compliance

Each Fireguard® tank is:

UL-2085 listed
Fabricated per Steel Tank Institute Fireguard® specifications
Delivered with documentation for code and insurance verification

Let’s Get Started

At STAFCO, we take pride in providing personal service—plain and simple. Contact us today to request a quote or speak with our team about UL-2085 Fireguard® tank options.

2085 Fireguard Tanks

Gallons	Tank Size	RFQ	Image
300	38"D X 5'-0"L INNER 10ga/10ga	Request Quote	Image Coming Soon
550	46"D X 6'-6"L INNER 10ga/10ga	Request Quote	View Image
1,000	46"D X 12'0"L INNER 10ga/10ga	Request Quote	View Image
2,000	64"D X 12'-0"L INNER 7GA	Request Quote	Image Coming Soon
3,000	64"D X 18'-0"L INNER 7GA	Request Quote	Image Coming Soon
4,000	64"D X 24'-0"L INNER 7GA	Request Quote	Image Coming Soon
5,000	96"D X 14'-0"L INNER 1/4"	Request Quote	View Image
6,000	96"D X 16'-0"L INNER 1/4"	Request Quote	Image Coming Soon
8,000	96"D X 21'-4"L INNER 1/4"	Request Quote	Image Coming Soon
10,000	96"D X 27'-0"L INNER 1/4"	Request Quote	Image Coming Soon
12,000	120"D X 20'-8"L INNER 1/4"	Request Quote	View Image

If you don’t see the exact size you need, feel free to contact us to review your requirements.
